Current location:Home > Products >Thick Film Chip Resistors > Wide Terminal Thick Film Chip Resistors - WR

Click to show

Show 30 Series results

If you need to download the specifications of related products, please click the box in front of your required specifications to be checked, please click the Download PDF button at the top of the form to download the complete specifications .
Download PDF
Series Product Name Photo Power Specifications Temperature coefficient Precision Resistance segment Specifications Details
WR Wide Terminal Thick Film Chip Resistors WR25 ±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 2W WR25 ±100ppm/℃ ±0.5%,±1%,±5% 100Ω<R≤1MΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 2W WR25 ±200ppm/℃ ±0.5%,±1%,±5% 1Ω<R≤100Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 3W WR25 ±200ppm/℃ ±0.5%,±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 3W WR25 0~+100ppm/℃ ±0.5%,±1%,±5% 30mΩ≤R<1Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 3W WR25 0~+150ppm/℃ ±0.5%,±1%,±5% 10mΩ≤R<30mΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors WR20 ±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 ±100ppm/℃ ±0.5%,±1%,±5% 100Ω<R≤1MΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 ±200ppm/℃ ±0.5%,±1%,±5% 10Ω≤R≤100Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 ±200ppm/℃ ±5% 1Ω≤R<10Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 ±200ppm/℃ ±0.5%,±1%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 0~+100ppm/℃ ±0.5%,±1%,±5% 30mΩ≤R<1Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR20 0~+200ppm/℃ ±0.5%,±1%,±5% 10mΩ≤R<30mΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors WR18 ±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR18 ±100ppm/℃ ±0.5%,±1%,±5% 100Ω<R≤1MΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR18 ±200ppm/℃ ±0.5%,±1%,±5% 1Ω≤R≤100Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR18 0~+100ppm/℃ ±0.5%,±1%,±5% 30mΩ≤R<1Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR18 0~+200ppm/℃ ±0.5%,±1%,±5% 10mΩ≤R<30mΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors WR12 ±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1/2W WR12 ±100ppm/℃ ±0.5%,±1%,±5% 1KΩ<R≤1MΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR12 ±100ppm/℃ ±0.5%,±1%,±5% 100Ω<R≤1KΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR12 ±200ppm/℃ ±0.5%,±1%,±5% 1Ω≤R≤100Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR12 0~+150ppm/℃ ±0.5%,±1%,±5% 100mΩ≤R<1Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1W WR12 0~+200ppm/℃ ±0.5%,±1%,±5% 10mΩ≤R<100mΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors WR08 ±1%,±5%
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1/3W WR08 ±100ppm/℃ ±0.5%,±1%,±5% 100Ω<R≤1MΩ
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 1/3W WR08 ±200ppm/℃ ±0.5%,±1%,±5% 10Ω≤R≦100Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 2/3W WR08 ±200ppm/℃ ±0.5%,±1%,±5% 1Ω≤R<10Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 2/3W WR08 0~±150ppm/℃ ±0.5%,±1%,±5% 30mΩ≤R<1Ω
File size:651.27 KB
Details
WR Wide Terminal Thick Film Chip Resistors 2/3W WR08 0~±400ppm/℃ ±0.5%,±1%,±5% 10mΩ≤R<30mΩ
File size:651.27 KB
Details
